ProductIn developing the LC interface, we aimed to deliver more than leading-the-art features. You also get a unique combination of advantages with superior form and function that make you feel more comfortable with the LC interface choice.

Advantages in form
Fit twice as many small-form-factor (SFF) ports as SC or ST ports, since SFF is half the size of SC connector (on a duplex or two-fiber connection)

Drawing gifFit copper or fiber in the same real estate-24 copper ports or 24 duplex LC ports in the same panel space, thanks to the higher density SFF interface

Save space on patch panels and communications outlets
Please users with familiar RJ-style latching
Interchange SFF transceivers from different vendors, thanks to common footprint.

Advantages in function
Facilitate high-speed applications with lower power requirements due to lower insertion loss (0.1 dB typical) and higher return loss (55 dB single-mode)
Put up to six interconnections in the path thanks to additional power margin
Avoid transceiver waveguide technology, thanks to wider fiber pitch (6.25 mm) that avoids crosstalk without using noise-avoidance mechanisms that can add up to a 2-dB output power penalty
Speed mounting with no-polish/no-epoxy version; for polish versions, smaller diameter LC endface reduces polishing time.

The Design Advantage
Join vendors using over 40,000,000 LC connectors proving themselves in the field

Source from all LC Alliance™ members for LC-based transceivers, who are delivering 10 Mb/s to 2.5 Gb/s products now

Meet multisource agreements (MSA) for both through-hole and pluggable transceivers
Meet IEEE 1394 FireWire and TIA/EIA-568B standards
Satisfy gigabit speeds of Ethernet, Fibre Channel, ATM, SONET, plus lower speeds of 10Base-FL, Fast Ethernet, and 155- and 622-Mb/s ATM.
